Leica Elmarit-TL 18mm F2.8 ASPH

Leica L-Mount Autofocus

Leica Elmarit-TL 18mm F2.8 ASPH

Focal length
18 mm
Aperture
f/2.8
Weight
80 g
Filter diameter
39 mm
Min. focus distance
30 cm
Length
21 mm
Check price on Amazon 1

At a Glance

This wide-angle prime for APS-C on L-Mount has an 18 mm focal length, equivalent to 27 mm on full frame. It weighs just 80 g, measures 21 mm in length and opens to f/2.8. Autofocus with manual override and a non-rotating filter mount are included. It suits landscape, reportage, vlogging and travel, but on full-frame cameras only crop mode is usable.

Good for

  • Landscape
  • Reportage
  • Vlogging
  • Travel

Worth knowing

  • APS-C image circle: on full-frame cameras only usable in crop mode, at reduced resolution.

Derived from the manufacturer data, not from our own tests. How we check

Technical Specifications

Report an error

Is a value wrong or missing for Leica Elmarit-TL 18mm F2.8 ASPH? Tell us what is wrong.

Min. focal length
18 mm
Max. focal length
18 mm
Max. aperture (min. zoom)
f/2.8
Max. aperture (max. zoom)
f/2.8
Min. aperture
f/16
Elements
8
Groups
6
Weight
80 g (0.18 lb)
Filter diameter
39 mm
Min. focus distance
30 cm (11.81 in)
Max. magnification
1:14.1 (0.07×)
Length
21 mm (0.83 in)
Diameter
62 mm (2.44 in)

Manufacturer data: leica-camera.com

Last checked: October 13, 2026 (against the manufacturer data) · How we check

Simulate depth of field and angle of view

Compare with other lenses

Which cameras does the Leica Elmarit-TL 18mm F2.8 ASPH fit?

The Leica Elmarit-TL 18mm F2.8 ASPH is designed for APS-C sensors. On APS-C L-Mount cameras its field of view equals 27 mm in full-frame terms. Full-frame bodies use it in APS-C (crop) mode, recording only part of the sensor and fewer megapixels.

L-Mount cameras

Full frame (in APS-C mode):
Leica SL3-P,Leica SL3-S,Sigma BF,Panasonic Lumix S1II,Panasonic Lumix S1IIE,Panasonic Lumix S1RII,Leica SL3,Panasonic Lumix S9,Blackmagic PYXIS 6K,Panasonic Lumix S5II,Panasonic Lumix S5IIX,Blackmagic Cinema Camera 6K,Panasonic Lumix BS1H,Leica SL2-S,Panasonic Lumix S5,Sigma fp L,Leica SL2,Panasonic Lumix S1,Panasonic Lumix S1R,Panasonic Lumix S1H,Sigma fp,Leica SL (Typ 601)
APS-C:
Leica CL,Leica TL2,Leica TL,Leica T (Typ 701)

Leica Elmarit-TL 18mm F2.8 ASPH compared

Key specs side by side with the most similar L-Mount lenses.

LensLeica Elmarit-TL 18mm F2.8 ASPHViltrox AF 20mm F2.8Panasonic Lumix S 18mm F1.8AstrHori 18mm f/5.6 Shift
Focal length18 mm20 mm18 mm18 mm
Max. aperturef/2.8f/2.8f/1.8f/5.6
Weight80 g159 g340 g–
Filter diameter39 mm52 mm67 mm58 mm
Min. focus distance30 cm19 cm18 cm30 cm
Length21 mm52.3 mm82 mm36 mm
Autofocusyesyesyesno
Image stabilizationnononono
Open these lenses in the comparison and add more

Leica Elmarit-TL 18mm F2.8 ASPH: FAQ

Does the Leica Elmarit-TL 18mm F2.8 ASPH have autofocus?

Yes, the Leica Elmarit-TL 18mm F2.8 ASPH has autofocus.

Does the Leica Elmarit-TL 18mm F2.8 ASPH have image stabilization?

No, the Leica Elmarit-TL 18mm F2.8 ASPH has no stabilization of its own. On cameras with in-body image stabilization (IBIS) the image is still stabilized.

How much does the Leica Elmarit-TL 18mm F2.8 ASPH weigh?

The Leica Elmarit-TL 18mm F2.8 ASPH weighs 80 g. It is 21 mm long with a diameter of 62 mm.

What filter size does the Leica Elmarit-TL 18mm F2.8 ASPH use?

The Leica Elmarit-TL 18mm F2.8 ASPH takes 39 mm screw-in filters.

How close can the Leica Elmarit-TL 18mm F2.8 ASPH focus?

The minimum focus distance of the Leica Elmarit-TL 18mm F2.8 ASPH is 30 cm, measured from the sensor plane.

Is the Leica Elmarit-TL 18mm F2.8 ASPH a full-frame lens?

No, the Leica Elmarit-TL 18mm F2.8 ASPH is an APS-C lens. On APS-C cameras its field of view equals 27 mm in full-frame terms.
